BPS 2315ER

SKU: BPS 2315050ER

Butterfly valve stainless steel

DN: 50
BYGGLÄNGD : 43
PN: 16
Price:
Sale price0 kr

This butterfly valve has a wafer type connection and is mounted between two flanges. Body made of stainless steel which makes it suitable for a more aggressive surrounding environments. Standard lining is EPDM rubber and the valve has an ISO 5211 flange for direct mounting of actuators. It has a stem bushing of PTFE between the body and shaft to ensure that the valve is easily operated over time. Face to face according to DIN EN 558-1 series 20 (K1). The valve is controlled by an electric actuator 230 VAC with 4-20 mA or 0-10 VDC.

Description

Body: Stainless steel AISI316
Disc: Stainless steel AISI316
Lining: EPDM
Connection: Wafer
Temp: -15°C - +110°C
